منشار بوش (GST680) استطاعة (500W) مزود بأربعة إعدادات وقاعدة قابلة للتعديل

Key specs include a 500 W motor, 800–3100 spm, 20 mm stroke length, cutting depths of 68 mm in wood, 10 mm in aluminium, and 3 mm in non-alloy steel, a bevel range from -45° to 45°, four pendulum settings, an ergonomic soft-grip handle, and an integral dust extraction system. It also includes an anti-splinter guard and a 4 mm hex key.

Pendulum action changes how aggressive the cut is. With pendulum off, you get cleaner, slower cuts ideal for fine joinery in wood. Increasing pendulum action speeds up wood cutting but can produce rougher edges. The GST 680 provides four settings to balance speed and cut quality across different materials.

Wood cuts up to 68 mm deep; aluminium up to 10 mm; non-alloy steel up to 3 mm. Use appropriate blades for each material (wood blades for wood, metal blades for metal, with the right tooth geometry).

Use the footplate for bevel cuts. Loosen the adjustment screws, tilt the base to the desired angle between -45° and 45°, then retighten the screws. The included 4 mm hex key can be used to tighten the screws.

Select blades with appropriate tooth geometry for wood, metal or plastic, and use T-shank blades for a quick blade change. For clean wood cuts, use blades with finer teeth; for faster metal cuts, use bi-metal blades designed for metal.

The GST 680 has an integral dust extraction port. Connect a direct dust-extractor hose to the tool or use it with your all-purpose dust extractor to keep the work area clean.

Always unplug before changing blades, wear safety glasses and hearing protection, clamp the workpiece, keep fingers away from the blade, use the dust collection system, and avoid forcing the tool; let the blade do the work and maintain a steady feed.

Regularly clean dust from the base and motor housing, inspect blades for wear, replace blades promptly, check the dust extraction port and hose for blockages, and store the tool in a dry place.

When comparing on Fepy, consider motor power, stroke length, cutting depth, speed range, pendulum action, bevel capacity, and dust management. For example, alternatives like Bosch GST 8000 S (https://fepy.com/product/bosch-gst-8000-s-professional-jigsaw), Bosch GST 7000 (https://fepy.com/product/bosch-gst-7000-jigsaw), and Makita JV0600 (https://fepy.com/product/makita-jv0600k-jigsaw) offer different balances of power, features, and price to suit various needs.

Yes. The GST 680 combines solid power, versatile cutting (including bevels and deep wood cuts), effective dust extraction, and adjustable pendulum action, making it a well-rounded option for both serious DIY and professional projects at a competitive price point.

Unpack and inspect for damage, install a suitable blade, connect dust extraction if desired, set the bevel to 0°, select the desired pendulum setting, set the speed, and plug in. Start at a lower speed to test cuts on scrap material.
