Legrand Mallia Senses 1 Gang 5 to 300 Watts Incandescent or 5 to 75 Watts LED Rotary Dimmer 100 to 230 Volts 50/60Hz Matt White 281086MW

Legrand Mallia Senses 1 Gang 5 to 300 Watts Incandescent or 5 to 75 Watts LED Rotary Dimmer 100 to 230 Volts 50/60Hz Matt White 281086MW

The Legrand Mallia Senses 1 Gang 5 to 300 Watts Incandescent or 5 to 75 Watts LED Rotary Dimmer 100 to 230 Volts 50/60Hz Matt White 281086MW is a single gang push on off rotary dimmer from the Mallia Senses range for dimmable LED, incandescent and halogen lighting, finished to match Mallia Senses switches and sockets.

• Push on off with rotary level control

• Dimmable LED and CFL up to 75W

• Incandescent and halogen up to 300W

• Light level memory

• Leading and trailing edge operation

• Works without a neutral conductor

Range

Mallia Senses

Product type

Rotary dimmer

Number of gangs

1

Incandescent and halogen load

5 to 300W

Dimmable LED and CFL load

5 to 75W

Dimming method

Leading and trailing edge

Control

Push on off rotary knob

Dimming range

10 to 100 percent

Voltage

100 to 240V AC

Frequency

50/60Hz

Neutral

Not required

Terminals

Screw terminals, 1 to 4 sq mm

Minimum box depth

35mm

Dimensions

86 x 86 x 57mm

Material

Halogen free thermoplastic

Protection

IP20, IK04

Colour

Matt White

Model number

281086MW

How to Use

Isolate the supply. Connect the live and switched live conductors to the marked terminals, fix the dimmer to the back box and restore power. Push the knob to switch on or off and turn it to adjust brightness. Use dimmable lamps only within the rated load.

Applications

Living rooms, bedrooms, dining areas, hotel rooms and offices using dimmable LED or halogen lighting.
