Question 1

What is the Matsuda E100 Floor Standing Eye Washer, SS and what does it do?

Accepted Answer

It’s a pedestal-mounted, free‑standing eye/face wash designed for quick emergency flushing. Built from stainless steel, it features two spray heads, dust covers, and a flow control/filter assembly, and can be activated by a flag handle or a foot treadle for fast access.

Question 2

What are the key specifications I should know?

Accepted Answer

Key specs include: stainless steel construction, 11-1/2 inch diameter bowl, two spray heads with dust covers, 1/2 inch inlet for water supply, 1-1/4 inch outlet for waste, working pressure 0.2–0.8 MPa, maximum static pressure 0.9 MPa, and factory‑assembled, ready for installation.

Question 3

How is activation performed in an emergency?

Accepted Answer

Activation can be done using either the flag handle or the foot treadle. Once activated, the valve stays open and the unit continues to flush until it is manually closed.

Question 4

What about water flow and keeping the water clean?

Accepted Answer

Each spray head includes a dust cover and a built-in filter to help remove impurities. The system provides a steady, clean flow suitable for emergency eye/face flushing, with flow controlled by the unit’s valve and heads.

Question 5

What are the inlet/outlet connections and mounting details?

Accepted Answer

The unit connects to a 1/2 inch water supply inlet and uses a 1-1/4 inch waste outlet. It is mounted as a free-standing pedestal, with an 11-1/2 inch diameter stainless steel bowl designed for comfortable user access.

Question 6

Where would this unit typically be installed?

Accepted Answer

Ideal for industrial floors, manufacturing areas, laboratories, and any workspace where quick eye/face flushing is needed in case of exposure to hazards.

Question 7

How do I maintain and service the Matsuda E100 Eye Washer?

Accepted Answer

Regular maintenance includes inspecting and cleaning the spray heads and dust covers, checking the flow, flushing the system, and ensuring the filter remains unobstructed. Periodic checks help ensure the unit remains ready for use.

Question 8

How does the Matsuda E100 compare to other eye washers available on Fepy?

Accepted Answer

Compared to other options, the E100 offers a robust free-standing pedestal design with a larger bowl and dual spray heads for quicker coverage on floor‑mounted installations. For alternatives on Fepy, you can review Matsuda E80 Eye Washer, SS (https://fepy.com/products/matsuda-e80-eye-washer-ss) and Matsuda E200 Floor Standing Eye Washer, SS (https://fepy.com/products/matsuda-e200-floor-standing-eye-washer-ss).

Question 9

What should I consider before buying this eye washer?

Accepted Answer

Consider activation method (flag handle vs. foot treadle), mounting type (pedestal floor-standing), water supply and waste connections (1/2" inlet, 1-1/4" outlet), required working pressure range, and whether you need the unit to be factory assembled for quick installation.

Question 10

What is included with the Matsuda E100 when it’s delivered?

Accepted Answer

The unit is factory assembled and includes the two spray heads with dust covers, flow control, and filter assembly, along with activation options (flag handle or foot treadle) as part of the pedestal-mounted design.

Question 11

Can this eye washer be used for both eye and full-face washing?

Accepted Answer

Yes. The E100 is described as an eye/face wash unit, designed to provide effective flushing for eyes and the surrounding facial area in emergency situations.
